Lightwalltrap

Absorption face
Diffusion face




/

Studios' large rooms are adequate to record joint “takes”, with all the band's elements playing at the same time. The WALLBLIND® is recommended to physically divide the musicians or the several sound sources between each instrument or amplifier, thus minimizing both the complicity and sound contamination of the several instruments in relation to the microphones.

The WALLBLIND® is a portable acoustic blind system which is ideal for your recording room. It provides a remarkable acoustic division while permitting to choose the most pleasant face for the instrument that it surrounds.

You can choose from two faces with different acoustic and aesthetic features: one side has a high-density EPS profile, which is hardened with a ceramic painting film, with good diffusing features, while the other side has an optimised profile cut for open-cell acoustic foam, thus being quite more absorbent.

This versatility offers therefore several loudness and modulation options for good sound recording in your room.

This product has a resistant rigid structure with big wheels and allows several modules to be coupled with quite tight union angles.

In addition to the standard sizes, models with a glass viewfinder or other sizes, as needed, are also available upon order.


Features:

  • Wheeled acoustic blind s
  • NRC : 0.66.
  • Solid structure, excellent insulation.
  • Two acousticaly different faces (diffusing and absorbent)
  • Ideal to separate and surround instruments
  • Place: recording and rehearsal studios
  • Installation: easy to install on the provided base
  • Package: 2 units.
  • Dimensions: 200cm X 120 cm X 14cm.
  • Available colours: grey, blue, red and cream.
Ref LIG090

Peso
Altura
Largura
Profundidade

51.4 Kg
200 cm
120 Cm
51.4 Cm


NRC =0.66 - WALLBLIND®


αs

.02
.03
.08
0.15
0.25
0.32
0.33
0.35
0.35
0.39
0.42
0.43
0.48
0.59
0.62
0.64
0.67
0.70
0.69
0.67
0.68
0.69
0.72
0.71

0.49 FOAM

.01
.02
.09
0.37
0.46
0.54
0.60
0.71
0.74
0.70
0.78
0.80
0.83
0.80
0.75
0.69
0.64
0.59
0.57
0.60
0.87
0.88
0.86
0.87

.66 EPS



αs


1.4
1.2
1.0
0.8
0.6
0.4
0.2


FREQUENCY (HZ)


Values in accordance with the Standards: EN20654, ASTM C423 e EN 11654

Values [<100Hz and > 5K] are Non Standard Values
JOCAVI® products are certified by the F.E.U.P. acoustic laboratory.
