DESCRIPTION

Auditoriums, music audition rooms, studios, practice rooms, etc., need a surface that is efficient at absorbing sound waves within the largest possible range of frequencies. The MELLOWALLTRAP® is an absorbent panel meant to be installed on walls and ceilings. This product is particularly important for absorbing the mid and mid-high range of the sound spectrum. This panel excels due to its high performance, small size and low weight. Although it is manufactured with the best absorbent materials of medium frequencies, JOCAVI® added to those materials a mathematically-studied form of incisions in order to increase and improve its results. The MELLOWALLTRAP shape was designed to absorb the incident sound on walls and ceilings, thus reducing the reflected energy at the hearing point and eliminating, to some extent, the room effect. It is an absorption panel which is highly efficient in the mid-range of the sound spectrum

FEATURES
Uses 75% of recycled materials
NRC: 0.95/m2.
100% Recyclable
Fire-resistance: Euroclass B (similar to old M1)
Package: 2 and 4 units.
Installation: accessories included.

Other sizes are available on demand
MODELS
HEIGHT
WIDTH
DEPTH
WEIGHT
MEL180
180 cm
60 cm
8 cm
12 Kg
MEL120
120 cm
60 cm
8 cm
8 Kg
MEL060
60 cm
60 cm
8 cm
4 Kg






MODELS AND SIZES



ABSORPTION COEFFICIENTS

Frequency [HZ]

STANDARD FABRIC COLOURS
BEIGE
Similar to
RAL 1011
YELLOW
Similar to
RAL 1003
ORANGE
Similar to
RAL 2001
RED
Similar to
RAL 3003
PURPLE
Similar to
RAL 4007
LIGHT BLUE
Similar to
RAL 5010
GREEN
Similar to
RAL 6028
BROWN
Similar to
RAL 8019
LIGHT GREY
Similar to
RAL 7001
GREY
Similar to
RAL 7015
BLACK
Similar to
RAL 9005
BLUE
Similar to
RAL 5013

WHITE
Similar to
RAL 9003
