ECOiso® ABL® Absorbent Layer


The ECOiso® ABL® absorbent layer, is a construction finishing material with acoustic absorbing properties. Following an ecological philosophy, JOCAVI® has developed this line of acoustic treatment materials, which are made exclusively from natural raw-materials, like recycled wood fibres and coconut fibres.

This line of products provides a practical and efficient solution for acoustic treatment. It is composed of coconut fibre (as an energy absorbent material), and perforated panels made of coloured pressed wood fibre or natural wood finishing colours that gives it an attractive good looking finishing. This compound, made of strictly 100% natural ecological materials, has an excellent technical performance.

The ECOiso® ABL® is ideal to install in auditoriums, conference rooms, business spaces, restaurants and bars, etc.. The coconut fibre is a natural, renewable and very light vegetal material. It has high porosity (95% of pores), which translates into an extremely high absorption of sound energy.The good behaviour of the recycled wood fibres, associated with the coconut fibre's micro-porous absorbent properties, makes a natural first-class combination in terms of acoustic solutions.

The acoustic behaviour of the ECOiso® ABL® (coconut + wood) delivers a natural combination, and ensures solutions with superb acoustic
performances to reduce airborne levels, as well as an excellent aesthetical and decorative integration.


Features
100% natural materials
Fire Class: B-s2, d0 - E1
100% recycled and recyclable
Unlimited durability, no loss of features
Noise reduction coefficient (NRC): 0,78
Low energy consumption during the manufacturing process
Excellent dimensional stability (even when subject to high thermal variations)

Model
Dimmensions
Weights
ABL 060
60 x 60 x 2.8 cm
2.2 kg
ABL120
120x 60x 2.8cm
4.1 kg


COMPOSITION
The ECOiso® ABL® is composed of two materials (coconut fibres and recycled wood fibres) forming the Acoustic Absorber element, that gives us the final decorative finishing.


Mounting
Apply a thread of glue and, lastly, mount the acoustic absorption panels ECOiso® ABL® that provide the finishing. Remark: the plates may be cut with a saw to be adjusted to the limits of walls or ceilings.
back to top

ABSORPTION COEFFICIENT ABSORPTION COEFFICIENTS OF ALL MODELS (NRC**) AND FINISHING PANELS PERFORATIONS (%/m2)
Values for ECOiso® System - SPL®+ABL® **
Frequency [HZ]


  ABSORPTION COEFFICIENT:
Values in accordance with the standards: EN 20654, ASTM C423 and EN 11654.

MODELS AND STANDARD PERFORATIONS
ADDSORB®

LEAKY FM®

STANDARD WOOD VENEER FINISHINGS

PINE
OAK
CHERRY
MAHOGANY
BLACK/BROWN
SUCUPIRA


STANDARD COLOURED WOOD FIBRE COLOURS
