Description
DESCRIPTION

The DIAMOND® is a 3D-controlled dispersion multidirectional reflection panel with a depth factor that is logarithmically varied. It is, therefore, a three-dimension omnidirectional diffusion panel that controls primary reflections and fragments the energy in 64 vertices of incidence by using the theoretical numerical sequence ratio of the primitive root as a basis for calculation. It is built with ABS recyclable material, and its modular design makes it a particular and high-performance diffuser. The reflection angles were optimised according to mid-size room applications. The DIAMOND® is an acoustic diffusion element with a lozenge geometry. The front view refers to 64 interconnected polygons with four multiple sound diffusion angles, which determines a diamond shape. It was created in 16 singular modules that have a quadrangular base and different extrusion heights on each corner. The combination of those positions results in a geometrically scattering diffusion pattern with a very attractive shape. Thus, the DIAMOND® produces exceptional results of sound diffusion effect and provides spaces with considerable sound perception. Available in several colours.

FEATURES

Manufactured with ABS.
Average diffusion: 0.63/m2 [>100Hz;<5KHz]
NRC: 0.22/m2 [>100Hz;<5KHz]
Fire-resistance: M1
100% recyclable
Installation: mounting accessories included


MODELS AND SIZES

MODELS
HEIGHT
WIDTH
DEPTH
WEIGHT
DIA060
60 cm
60 cm
10.5 cm
4.5 Kg




DIFFUSION COEFFICIENTS

Frequency [HZ]
STANDARD ABS COLOURS

YELLOW
Similar to
RAL 1003
ORANGE
Similar to
RAL 2008
RED
Similar to
RAL 3001
PURPLE
Similar to
RAL 4005
LILAC
Similar to
RAL 4009

BROWN
Similar to
RAL 8017
BLACK
Similar to
RAL 9005
LIGHT GREY
Similar to
RAL 7042
WHITE
Similar to
RAL 9003
BLUE
Similar to
RAL 5013
