DESCRIPTION

This panel is related to the MELLOWALLTRAP® and the WALLTRAP® panels, as it is an absorption panel to be applied on walls and ceilings that predominantly absorbs in the mid-range of the sound spectrum. The similarities end there given that its size, technical characteristics and respective type of mounting are quite different. It is an acoustic panel that absorbs medium frequencies and has been developed for use in small rooms. This product is manufactured with raw materials of different mass and density which are duly coupled in order to increase its absorption coefficient as much as possible. Several panels can be assembled together with surprising results. As regards its size, it is one of the most effective panels available in the market.

FEATURES
Uses 65% of recycled materials
To apply in large rooms
NRC: 0.73/m2
100% Recyclable
Fire-resistance: M2
Package: unit.
Installation:* accessories included.

Other sizes available on demand

MODELS
HEIGHT
WIDTH
DEPTH
WEIGHT
LIG180
180 cm
90 cm
7 cm
20.3 Kg
LIG090
90 cm
90 cm
7 cm
11.2 Kg
LIG030
30 cm
90 cm
7 cm
3.8 Kg
LIGR090/120 **
-
Diameter 90/120 cm
7 cm
8.7/11.8 Kg
LIGC090
90 cm
90 cm
7 cm
9.5 Kg



MODELS AND SIZES
LIG30
LIG090
LIG180
LIGR090
LIGC090

ABSORPTION COEFFICIENTS

Frequency [HZ]

STANDARD FABRIC COLOURS
BEIGE
Similar to
RAL 1011
YELLOW
Similar to
RAL 1003
ORANGE
Similar to
RAL 2001
RED
Similar to
RAL 3003
PURPLE
Similar to
RAL 4007
LIGHT BLUE
Similar to
RAL 5010
GREEN
Similar to
RAL 6028
BROWN
Similar to
RAL 8019
LIGHT GREY
Similar to
RAL 7001
GREY
Similar to
RAL 7015
BLACK
Similar to
RAL 9005
BLUE
Similar to
RAL 5013

WHITE
Similar to
RAL 9003


** Motif option not available for the LIGR090/120 model

* Included suspension wires 60cm, different measures upon request.
