DESCRIPTION

The CONVEXABSORBER® is an absorbent panel which is efficient at absorbing low and medium frequencies. It was designed to be installed on ceilings and walls. It is manufactured by combining two techniques: a box tuned to 200 Hz, which is efficient at low frequencies, and a mathematically studied absorbent labyrinth, which provides this product with an excellent performance in absorbing sound. Given its characteristics, this panel balances reverberation times and echoes in large-sized rooms, auditoriums, etc.. Because of its large and convex shape, it also is a diffuser with a large dispersion surface. When the areas so require, these panels can be installed alternately at 90º angles, the dispersion thus being on two plans. The CONVEXABSORBER® panel was designed and tested in order to guarantee its high performance in controlling sound energy, by reducing resonances and reflections. It has a wide range of applications.

FEATURES
Uses 65% of recycled materials
To apply in large rooms
NRC: 0.81/m2
Fire-resistance: M2
Package: unit.
Installation: accessories included.



MODELS AND SIZES

MODELS
HEIGHT
WIDTH
DEPTH
WEIGHT
CON180
180 cm
114 cm
26 cm
35.1 Kg
CON120
120 cm
114 cm
26 cm
23.4 Kg



ABSORPTION COEFFICIENTS

Frequency [HZ]

STANDARD FABRIC COLOURS
BEIGE
Similar to
RAL 1011
YELLOW
Similar to
RAL 1003
ORANGE
Similar to
RAL 2001
RED
Similar to
RAL 3003
PURPLE
Similar to
RAL 4007
LIGHT BLUE
Similar to
RAL 5010
GREEN
Similar to
RAL 6028
BROWN
Similar to
RAL 8019
LIGHT GREY
Similar to
RAL 7001
GREY
Similar to
RAL 7015
BLACK
Similar to
RAL 9005
BLUE
Similar to
RAL 5013

WHITE
Similar to
RAL 9003
